Hand Hold Servo Motor Screwdriver

XYD is a factory founded in 2003 with a specialization in the production of Hand Hold Servo Motor Screwdrivers. Over the years, XYD has evolved into a comprehensive manufacturing entity that seamlessly integrates production, supply, design, development, and sales of smart screwdrivers. Renowned both domestically and internationally, XYD has earned recognition for its extensive product offerings and commitment to delivering high-quality solutions.

Model:YM-ZN-008

Send Inquiry

Product Description

XYD is a renowned and forward-thinking factory based in China, specializing in the production and supply of high-quality Hand Hold Servo Motor Screwdrivers. Serving a diverse and global clientele, XYD is committed to delivering top-notch technological solutions that cater to the unique demands of its customers. The company's dedication to excellence is evident in its use of cutting-edge technology and advanced manufacturing techniques, ensuring that its Handheld Servo Motor Screwdrivers stand at the forefront of innovation and quality in the market.

In-Line Torque YM-ZN-008 DC24V5A Servo Smart Screwdriver

Product Details:

Place of origin：China

Brand Name：XYD

Certification：CE

P/N：S01001000100001

Payment&Shipping Terms：

Minimum Order Quantity：1 set

Price：Negotiable

Packaging Details：Paper Box

Delivery Time: 1-4weeks

Payment Terms：TT

Name: Hand Hold Servo Motor Screwdriver

The Power Of Motor：DC24v5A

Speed：20-1000rpm

Rated Torque：0.02-0.08N.m

Bit Type：Half-moon/Hios

Accessories:Controller, Power Adapter，Cable

Features

• Adopting a closed-loop servo motor controller with higher accuracy up to ± 3% and 10 million times tightening life span even under low speed tightening situation.

• Concisely designed structure and directly connecting motor to save maintenance labor cost

• Multiple product series choices

• Equipped with an angle encoder to allow more flexible rotation need.

• Adopting current sensing method to achieve reverse and unlocking screw data recording

• The exterior material is made of aluminum-magnesium alloy, lightweight and durable, with better heat dissipation and corrosion resistance, able to cope with more complex and harsh working environment.

Specifications

Model Number	Compatible Controller	Applicable Bit Type	Torque			Free Speed	Length	Width	Weight
Model Number	Compatible Controller	mm	Kgf.cm	N.m	lbf.in	RPM	mm	mm	Kg
YM-ZN-008	YM-2448-05	Φ4 Half Moon/ Φ4 Hios	0.20-0.80	0.02-0.08	0.18-0.72	20-1000	197	28	0.33
YM-ZN-025	YM-2448-05	Φ4 Half Moon/ Φ4 Hios	0.50-2.50	0.05-0.25	0.45-2.25	20-1000	215	30	0.53
YM-ZN-050	YM-2448-105	Φ4 Half Moon/ Φ4 Hios	1.00-5.00	0.10-0.50	0.90-4.5	20-1000	222	33	0.67
YM-ZN-120	YM-2448-510	Φ5 Hios	2.00-12.00	0.20-1.20	1.80-10.80	50-1000	241	30	0.65
YM-ZN-150	YM-2448-10	HEX 6.35	5.00-15.00	0.50-1.5	4.50-13.50	50-800	247.5	34	0.84
YM-ZN-250		HEX 6.35	10.00-25.00	1.00-2.50	9.00-22.50	50-800	247.5	34	0.84
YM-ZN-600		HEX 6.35	20.00-60.00	2.00-6.00	18.00-54.00	50-600	247.5	34	0.89
YM-ZN-800		HEX 6.35	30.00-80.00	3.00-8.00	27.00-72.00	50-600	247.5	34	0.89
YM-ZN-1000		HEX 6.35	50.00-100.00	5.00-10.00	45.00-90.00	50-400	294.5	35	1.14
YM-ZN-1500		HEX 6.35	100.00-150.00	10.00-15.00	90.00-135.00	50-400	303.5	35	1.50
